Invacare®EtudePlus
4.4.2BrittVandLinesiderails
Lock/Upperposition
Pullupthetopwoodenside
railbar,untilthelockingpin
lockswithanaudibleclick
Release
Liftthetopwoodenside
railbarandpressthetwo
lockingringstogether .
Down/Lowerposition
Lowerthesiderail.
Usingasiderailheightextender
LineandBrittVsiderailscanbesupplementedbyaheight
extender .Asiderailheightextenderincreasestheallowed
mattressthicknessby15cm.
WARNING!
Riskofinjuryordeath
Amisappliedsiderailheightextendercouldfall
off.There’sanincreasedriskfortheusertofall
outofthebed.
–Makesurethatthesiderailheightextenderis
properlyattachedtothesiderail.Refertothe
usermanualofthesiderailheightextender.
–Makesuretousethecorrectheightextender
foryoursiderail(theshapemustmatchto
theshapeofthesiderail.Alabelonthe
heightextenderdeterminestowhichsiderailit
belongs.Seeimagebelow.
HeightextenderforLINE
siderail:
HeightextenderforBRITTV
siderail:
4.5Liftingpole
WARNING!
Riskofinjury
Thebedcantipifthehandleisused,whilethe
liftingpoleisturnedawayfromthebed.
–Theliftingpolealwayshastobepositioned
withthehandlehangingoverthebedarea.
–Donotexceedthemaximumloadofthelifting
pole;80kg.
4.5.1Placetheliftingpole
Theliftingpolecanbeplacedeitherontheleftortheright
sideoftheheadendofthebed.
1.Inserttheliftingpoleintotheliftingpoletubeandxit
withthengerscrew.
It’snotrequiredtotightenthengerscrew,incase
youwanttheliftingpoletoswingawaytotheside
ofthebed.
4.5.2Adjustingthehandleheight
Thehandleheightshouldalwaysbeadjustedtotheuser’s
need.
1.2.
A
A
1.HoldthecordoutwhileslidingtheplasticcordlockA
upwardsordownwardsuntilthehandlereachesthe
preferredheight.
2.Lockthehandlebypressingbackthecordinthelock
Aandpullthehandledownwards.
NOTICE!
Afteradjustingthehandleheight:
–Checkthatthetwocordsabovethecordlock
areparallelandinsidethecordlock.
–Makesurethecordisproperlylockedbypulling
thehandlehard.
4.6Adjustingthelegsection
Operatethelegsectionbyliftingthemattresshandle:
1.Up:Liftthemattresshandleonthelegsection.
2.Down:Liftthemattresshandleonthelegsectionright
upandthenlowerthelegsection.
1660128467-B
