TechnicalData
9TechnicalData
9.1Materials
MattressPlatform
Steel(powder-coated)
BedEnds
Steel(powder-coated)andMDF
SideRails
Steel(powder-coated),Woodor
Aluminum
LiftingPole
Steel(powder-coated),PPandPOM
Actuatorshousing,
Handcontrol,
Controlbox,Castors
andotherPlastic
parts
Materialaccordingtomarking(PA,PP ,
PE,ABS)
Boltsandnuts
Steel(Zinc-plated)
9.2Dimensions
Allmeasurementsarestatedincm.Allanglesarestatedin
degrees.Allmeasurementsandanglesarestatedwithout
tolerances.
Invacare®reservestherighttochangethestated
measurementsandangles.
EtudePluslowEtudePlus
Low
High
Low
High
A
219219219219
B
102102102102
C
20–6027–6733–7340–80
D
138–178145–185158–198165–205
Theanglebetweenthelowerlegsectionandhorizontalis
adjustablefrom0ºto15º.
Bedwithtiltfunction
9.3Weights
Max.patientweight
(providedthattheweightofthe
mattressandtheaccessoriesdonot
exceed35kg)
165kg
Max.safeworkingload
(patient+accessories)
200kg
EtudePlusstandardbed,complete,excluding
accessories
76.5kg
EtudePlusauto-regression,complete,
excludingaccessories
84.35kg
EtudePlusbedendwithextraplate–1piece19.0kg
EtudePlusbedendwithoutextraplate–1
piece
17.0kg
Mattresssupport,standardheadend22.5kg
Mattresssupportwithauto-regression,head
end
26.0kg
Mattresssupportwithauto-regression,head
end,withoutactuatorandcontrolbox
21.5kg
Mattresssupport,footend17.0kg
Mattresssupport,footend,electricalupper
legsection
21.35kg
Mattresssupportextension(10cm)
3.5kg
Mattresssupportextension(20cm)
5.5kg
ScalaBasic2siderail–1piece7.4kg
ScalaBasicPlus2siderail–1piece7.4kg
ScalaMedium2siderail–1piece8.9kg
ScalaDecubi2siderail–1piece10.3kg
BrittVsiderail–1side7.7kg
Linesiderail–1side4.5kg
Lineextendablesiderail–1side6.5kg
Liftingpole6.0kg
9.4Mattresssizes
Mattressmeasures(incm):
Siderail:
Min.
height
Max.
height
Min.
width
Min.
length
ScalaBasic2
101785–90200
ScalaBasicPlus2
101785–90200
ScalaMedium2
102285–90200
ScalaDecubi2
233185–90200
Line*,mattress
supportplatform
inlowposition
112288–90200
Line*,mattress
supportplatform
inhighposition
5
1588–90200
BrittV,mattress
supportplatformin
lowposition
112285–90200
BrittV,mattress
supportplatformin
highposition
5
1585–90200
*bothLinesiderailsstandardandextendable.
Min.density:38kg/m
3
60128467-B23
