Invacare®EtudePlus
8.DisconnectthefootHi/Lomotorcablefromthecontrol
box,guideitthroughtheopeningofthesupportforthe
backrestmotorandreconnectit.
9.PlacethemiddleofthefootHi/Lomotorcablecoiled
partonthehookatthebedend.
10.Guidethemainscablethroughtheframehooksonthe
sideofthebedtothepoweroutletandconnectit.
11.Beforetakingthebedintouse,checkthatallpartsrun
smoothlyandthatnomotorcablesarehangingonthe
oororbeingsqueezedwhilemovingbedsections.
3.7Installingsiderails
WARNING!
Riskofpersonaldamage
Thereisariskofentrapmentorsqueezing,while
assemblingordisassemblingthesiderail.
–Payattentiontoyourngers.
–Followinstructionscarefully.
–Aftereachassembly,checkthatallttingsare
properlytightenedandthatthesiderailhas
thecorrectfunction.
Removable3/4lengthsiderails
WARNING!
Riskofentrapment
There’sariskofentrapmentorsuffocation
betweenmattresssupport,siderailandbedend.
–Whenusingremovablesiderails,alwaysmake
surethatthedistancebetweenthebedend
andthesiderail’shandleupperedgeisless
than6cmintheheadendandmorethan32
cminthefootendofthebed.
3.7.1Scala2siderail
Mountingsiderail
1.
Placethesiderailoverthetopframewiththerelease
systemAattheheadendofthebed.
Theforklinksonthesiderailmustbemounted
accordingtotheinstructiononthesiderail.
2.
TightenthengerscrewsBtoattachthesiderailon
thetopframe.Makesureitissteadyandfastened.
Dismountingsiderail
1.LoosenthetwongerscrewsBandremovetheside
rail.
3.7.2BrittVandLinesiderail
WARNING!
Riskofentrapment/suffocation
Theusercangettrappedorfalloutofthebedif
thesiderailisnotcorrectlymountedordamaged.
–Makesurethatallglidingshoesarecorrectly
guidedintothebedendguideways.
–Makesurethatallsiderailbarsareabovethe
lockingpinandproperlylocked.
–Makesurethatthestrapsbetweenthebarsare
notdamagedorloose.
