Invacare Solara 3G - Using Armrest

4 OPERATION
Part No 1154295 41 Invacare® Solara®3G/Spree 3G Wheelchair
Using Armrest
1. Flip the armrest release lever to the unlocked position (Detail "A").
2. Pull the front of the flip back armrest straight up and out of the front arm socket and rotate towards the rear of the wheelchair.
3. Rotate the flip back armrest towards the front of the wheelchair and then downward into the front arm socket.
4. Flip armrest release lever to the locked (vertical) position (Detail "A").
FIGURE6 Using Armrest

WARNING
Make sure the locking mechanism is secured before using wheelchair.
Unlock Position
(Horizontal)
Locked Position
(Vertical)
DETAIL "A"
Flip Back Armrest
Armrest Release Lever
Front Arm
Socket
Flip Back Armrest
