4 OPERATION
Part No 1154295 53 Invacare® Solara®3G/Spree 3G Wheelchair
1. Make sure the wheelchair is on a level surface.
2. Engage the wheel locks.
3. Inform the occupant of the wheelchair that the wheelchair is about
to be reclined.
4. Make sure occupant's hands and body are clear of all pinch points.
5. Stand behind the wheelchair and grasp the adjustable angle stroller
handle firmly.
6. Pull up on the trigger release levers to release the gas cylinders.
7. Slowly, squeeze the trigger release levers and perform one of the
following:
• Reclining - Allow the back to recline to the desired angle.
• Returning to upright position - Pull up and push the stroller
handle towards the front of the wheelchair until the back is in
the upright position.
8. When the back reaches desired angle, slowly release the handles of
the recliner cable assemblies.
9. Disengage the wheel locks.
FIGURE18 Recliner Operation
Back
Trigger Release
Lever
