Invacare TDX SP2 - Battery Handling and Replacement; Replacing Batteries

Service
CAUTION!
Burnhazard
Riskofinjuryduetodischargedacid.
–Alwayswearacid-proofprotectivegloveswhen
handlingbatteries.
–Alwayswearprotectivegoggleswhenhandling
batteries.
Whattodoifacidisdischarged
–Alwaystakeclothingwhichhasbeensoiledby
ordippedinacidoffimmediately.
–Rinseanyareasofyourskinwhichhascome
intocontactwithbatteryacidoffimmediately
withplentyofwater .
Ifcontactwitheyesismade
–Youshouldalsoconsultaneyespecialist
immediatelyafterwards.
Whendisassembling,takecareofsmallpartssuchas
screwsandwashers.Putallsmallpartsdownsothat
theycanbeinstalledintherightsequence.
1.Removelegrests.
2.LoosenandremovehandscrewEonrearshroudA.
3.Removerearshroud.
4.DisconnectbatteryplugsB.
5.RemovetwohandscrewsDonfrontshroudC.
6.Pullfrontshroudupwardsandremoveit.
7.Pullbatterytrayforwardsasfarasthestop.
6.7.6Replacingbatteries
CAUTION!
Riskofinjuryandmaterialdamagesifbatteries
arehandledimproperly
–Installationofnewbatteriesmayonlybe
carriedoutbyauthorisedspecialists.
–Observewarninginformationonbatteries.
–Onlyusebatteryversionsstatedinspecications.
CAUTION!
Riskofreandburnsifbatteryterminalis
bypassed
Takegreatcaretomakesurethatbattery
terminalsarenevershortedwithtoolsor
mechanicalmobilitydeviceparts.
–Makesurethatbatteryterminalcapshavebeen
replacedifyouarenotworkingonthebattery
terminals.
CAUTION!
Riskofcrushing
Batteriescanbeextremelyheavy.Thisresultsin
injuryhazardstoyourhands.
–Handlebatterieswithcare.
CAUTION!
Riskofburns.Riskofinjuryduetodischarged
acid.
–Alwayswearacid-proofprotectivegloveswhen
handlingbatteries.
–Alwayswearprotectivegoggleswhenhandling
batteries.
Whattodoifacidisdischarged.
–Alwaystakeclothingwhichhasbeensoiledby
ordippedinacidoffimmediately.
–Rinseanyareasofyourskinwhichhascome
intocontactwithbatteryacidoffimmediately
withplentyofwater .
Ifcontactwitheyesismade.
–Rinseaffectedeyeunderrunningwaterfor
severalminutes.
–Youshouldalsoconsultaneyespecialist
immediatelyafterwards.
•Size2Phillipsscrewdriver
•5/8“Allenkey
•11mmwrench
Removingbatteries
1.Makebatteriesaccessibleasdescribedin6.7.5Making
batteriesaccessible,page32.
2.
RemoveterminalcapsA.
3.RemoveterminalboltsB.Firstremovenegativeterminal
screw.Afterthis,youcanremovepositiveterminal
screw.
4.RemoveconnectioncableCandconnectcablewith
mainfuseC.
5.Openbatterystrap.
6.LiftbatteriesDoutofbatterytrayE.
1532486-L33
