Invacare TDX SP2 - Mobility Device Setup (cont.)

Setup
Theuserweightandseatdepthhavestrong
inuencesonthechoiceofthecenterofgravity
(CoG).Iftheuserisheavyandtheseatdepthis
greater,thefocusshouldbethefartherback.For
bestpossibledrivingcharacteristicsofrear-wheel
drivewheelchairs,theweightshouldbedistributed:
30–40%frontand60-70%rear .Forcenterwheel
drivestheweightshouldbedistributed25%front,
50%centerand25%rear.
CAUTION!
Riskofdamageduetocollisionsofthelegrests
withotherpartsofthemobilitydevice
–Setthelegreststothesmallestanglebefore
adjustingtheseatcenterofgravity.
–Payattentionwithadjustingseatcenterof
gravitythatlegrestsdonottouchanyother
partsofwheelchair.Thisensuresthatthe
legrestscannotcollidewithotherpartsof
wheelchair.
Seatsystems
Fordetailson
•Standardseat
•Flexseat
•Contourseat
•Maxseat
refertorevision11ofthisservicemanual.
FordetailsonModuliteseatseebelow.
4.1.4Moduliteseat
TheModuliteseatisavailableintwoversions:
•Telescopicseatframe(plateandstrap):Adjustmentof
centerofgravityviathelateralproles,asdescribed
belowin“Telescopicseatframe”.
•Onepieceseatplate:Adjustmentofcenterofgravity
viatheoblongholesoftheseatadapterasdescribed
belowinchapter“Onepieceseatplate”.
Telescopicseatframe
•6mmAllenkey
1.Removeseatplateorslingseat(1),seechapter
“Adjustingseatwidth”inModuliteservicemanual.
2.LoosenAllenscrews(2)infrontandrear,leftandright
–DONOTremove.
3.Shiftpositionofseat.
4.Tightenscrews.
5.Installseatplateorslingseat.
Onepieceseatplate(TDXSP2/TDXSP2NB)
•6mmAllenkey
1.Removeseatplate(1)orslingseat.Seechapter
“Adjustingseatwidth”inModuliteservicemanual.
2.LoosenAllenscrews(2)and(3)infrontandrear,left
andright–DONOTremove.
3.Shiftpositionofseatframe.
4.Tightenscrews.
5.Installseatplate.
Imperialtometricconversionchart
Youcanusethischartasanorientationtondtheright
toolsize.
IMPERIALMETRIC
inch
mm
5/64
1.9844
3/32
2.3813
7/64
2.7781
1/8
3.1750
9/64
3.5719
5/32
3.9688
11/64
4.3656
3/16
4.7625
13/64
5.1594
7/32
5.5563
15/64
5.9531
1/4
6.3500
17/64
6.7469
9/32
7.1438
1532486-L9
