Invacare TDX SP2 - Page 44

Invacare®TDX®SP2Series
ProblemOthersymptomsPossiblecauseSolution
Documentation
BadconnectionsCheckallcablingSee6.7.15Checking
cable,page38.
FuseburntoutCheckcablingand
replacefuse
See6.7.15Checking
cable,page38and
6.7.13Checkingand
replacingmainfuse,
page37.
BatteriesdefectiveReplacebatteriesSee6.7.6Replacing
batteries,page33
and6.7.9Replacing
batteries/replacing
batterycables,page35.
Cablingtopower
moduleorremote
defective
CheckcablingSee6.7.15Checking
cable,page38.
None
Powermodule
defective
ReplacepowermoduleSee6.7.1Replacing
powermodule,page31.
Motorsdonotrun
CorrodedcontactsContactsdefectiveCheckcabling,replace
ifnecessary
See6.7.15Checking
cable,page38.
Clutch(es)defective
ReplaceclutchSee6.4.7Replacing
motor/gearboxunit,
page23.
BearingdefectiveReplacemotorSee6.4.7Replacing
motor/gearboxunit,
page23.
Motormakesclicking
noise
None
CollectordefectiveMeasureinternal
resistanceofmotor,
replacemotorif
defective
See5.1Testing
motor,page11
and6.4.7Replacing
motor/gearboxunit,
page23
Clutch(es)defective
ReplaceclutchSee6.4.4Replacing
motor/gearboxclutch,
page22.
BearingdefectiveReplacemotorSee6.4.7Replacing
motor/gearbox
unit,page23and
6.4.4Replacing
motor/gearboxclutch,
page22.
Scrapingnoiseor
motorblocked
None
GearboxdefectiveReplacegearboxSee6.4.7Replacing
motor/gearbox
unit,page23
and6.4.4Replacing
motor/gearboxclutch,
page22.
GearboxdefectiveReplacegearboxSee6.4.7Replacing
motor/gearbox
unit,page23and
6.4.4Replacing
motor/gearboxclutch,
page22.
Gearboxmakesclicking
noise
None
DrivewheellooseTightendrivewheel,
secureboltswith
Loctiteifnecessary
See6.4.7Replacing
motor/gearboxunit,
page23.
44
1532486-L
