Inventis TIMPANI User Manual

46
Calibration
Duration of calibration:
12 months
Calibration reference:
IPSI: EN ISO 389-2
Acoustic couplers
For probe: IEC 60318-5
Reference equivalent
threshold levels
Frequency
[Hz]
IPSI RetSPL
[dB SPL]
125
-
250
-
500
11
750
-
1000
5.5
1500
-
2000
7
3000
-
4000
2
6000
-
8000
-
Patient management
Number of patients storable
50
Details memorized
Patient details (first name, last name, date of birth, gender)
Date and time of test
Tympanogram (Rx + Lx)
Reflex curve (Rx + Lx)
Physical specifications
Display
LCD TFT 2.8”
Viewing area 43.2 mm x 57.6 mm
Resolution 240x320xRGB
Touchscreen
Capacitive
Dimensions of
Tympanometer instrument
(WxDxH) 65 x 44 x 240 mm / 2.6 x 1.8 x 9.5 in
Weight of instrument
340g / 12 oz
Dimensions of charging
base
(WxDxH) 109 x 83 x 131 mm / 4.3 x 3.3 x 5.2 in
Weight of base only
280g / 9.9 oz
Tympanometer connectors
AC headphone
For future use
Patient response button
Input, 2.5 mm mono audio jack, 4Vpp max (for future use)
USB
I/O, mini B type, 5.5Vdc max
Charging base contacts
I/O, target type for spring-loaded contact, +/-10Vpp
Charging base connectors
USB
I/O, 2 x mini B type, 5.5Vdc max
Charging base contacts
I/O, spring-loaded contact, +/-10Vpp
Power supply
Battery
Rechargeable lithium ion type, standard 18650, 3.7V 2600mAh
