8. Part Names and Their Functions
CAUTION:
Wrong wiring connection will cause electrical malfunction.
Do not pull the wire when fixing it with wire
Notes:
1. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard.
2. The appliance will be installed in accordance with national wiring regulations.
States of the Indicating Lamps:
1. Indicating Lamp of “POWER”: The
indicating lamp will shine when power on,
while it will go out when power off.
2. Indicating Lamp of “COOL” :
3. The indicating lamp will shine when
“COOL” is activated, while it will go out
when “COOL” is deactivated.
4. Indicating Lamp of “HEAT”: The indicating
lamp will shine when “HEAT” is activated,
while it will go out when “HEAT” is
deactivated.
5. Indicating Lamp of “TIMER”
6. The indicating lamp will shine when
“TIMER” is activated, while it will go out
when “TIMER” is deactivated or the set
Communication cable
Remote controller
Refri
g
erant tube
Drain pipe
Fig.30
