13. Appendix
Air Conditioner Normal Working Conditions and Working Rang:
Notes:
1. The design of this unit conforms to the requirements of EN14511 standard.
2. The air volume is measured at the 0Pa external static pressure.
3. Cooling (heating) capacity stated above is measured under nominal working conditions
corresponding to 0Pa external static pressure. The parameters are subject to change with the
improvement of products, in which case the values on the nameplate will prevail.
This product must not be disposed together with the
domestic waste but disposed at the authorized place for
the recycling of electric and electronic appliances.
Indoor Side Outdoor Side
Test Condition
DB(℃) WB(℃) DB(℃) WB(℃)
Nominal Cooling 27 19 35 24
Nominal Heating 20 — 7 6
Rated Cooling 32 23 43 26
Low Temp.
Cooling
21 15 18 —
Rated Heating 27 － 24 18
Low Temp.
Heating
20 — -7 -8
