39
Fig.39
12.2 Installation of the Indoor Unit
When install the indoor unit, you can use a paper pattern for reference and make sure that the
drainage side be 10mm lower than the other side in order to drain the condensation water fluently.
Table.6
Model A B C D E
1220 225 1158 700 280
1420
245
1354
700
280
1700
245
1634
700
280
V1KI-09
V1KI-12
V1KI-18
V1KI-24
V1KI-30
V1KI-36
V1KI-45
V1KI-50
V1KI-60
