43
Fig.49
CAUTION
Installation in the following places may cause problems
If it is unavoidable to select such places, consult with your distributor or dealer.
1. A place with machine oil
2. A saline place such as a place very close to seashore
3. A place with corrosive gas
4. A place where high-frequency waves are generated by the radio equipment, welder or medical
equipment.
12.3.2 Electric Wiring Connection
Fig.50 Fig.51
CAUTION!
1. Wrong wiring may cause fire or
electric shock.
2. Do not pull the wire when fixing it
3. With wire clamps and clasps.
4. Do not let the wire too loose
5. All the electrical work must be
done by qualified personnel
according to the local rules and this
instruction
6. The rated voltage and the exclusive
Fig.52
U1RS-09
U1RS-12
U1RS-18 U1RS-24
U1RS-45
U1RS-48
U1RS-30
U1RS-36
U1RT-36
U1RT-45
U1RT-50
U1RT-60
To Next Page
