SERVICE MANUAL ODE-3 FRAME SIZE 3
Page 19 of 23
Control board (Digital inputs/outputs, Comms & display)
220V & 480V
Digital input 1 MODBUS
Digital input 2 User relay 1
Display Analogue output 1
Optibus Analogue output 2
