2016
SERVICE MANUAL ODE-3 FRAME SIZE 3
Page 23 of 23
Hot 30-33
12. Measure Output Current on Probe. Reduce to half speed and switch to Current on
Display.
13. Slowly increase load if possible to force drive to flash  (flashing dots on
display) and trip out  (over Current).
14. Reduce speed and load signals to 0 and open Dig Input 1 - press stop to clear OI trip.
15. Check thermistor value again in , it should increase in value due to the heat
difference.
16. Drive should read . Press ALL BUTTONS, display should show all 8’s. Let go of
the centre
NAVIGATE button whilst still holding UP, DOWN, START and STOP to reset drive (P-def),
press STOP once more to clear P-def from display. Display now shows STOP.
17. Power down unit and disconnect leads. Tighten all Power/Motor terminals.
18. Ensure all paperwork is correct with unit - clean and pack unit and arrange for return to
customer.
