Invertek Optidrive E3 Series User Manual

Easy Start Guide
Page 1
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
Page 1
Page 7
Page 6
Page 5
Page 2
Page 4
Page 10
Page 11
Page 9
Page 12
Page 13
Page 3
Page 14
Page 8
How to set a Parameter value
Power and Motor Connections (Single Phase)
Power and Motor Connections (Three Phase)
Contents
Motor Connections - Star and Delta
Parameters to set before use
How to enable/disable Sensorless Vector mode
Parameters - Overview
How to Operate the Inverter from the keypad
How to connect and configure a Potentiometer
for remote speed control
How to connect and configure a Run/Stop switch
with Forward/Reverse selection
How to configure “3-Wire” control with Run
Forward Run Reverse and Stop pushbuttons
Brake Resistor Connection (size 2 and above)
How to connect and configure a Run Forward or
Run Reverse switch
How to Reset the Inverter to Factory Defaults
Contents
Invertek Optidrive E3 Inverter (IP20, 3ph output)

Invertek Optidrive E3 Series Specifications

General

Output Voltage	0 to input voltage
Protection Rating	IP20
Altitude	Up to 1000m without derating
Output Frequency	0-500 Hz
Overload Capacity	150% for 60 seconds
Cooling Method	Fan cooled
Input Voltage	200-240V, 380-480V
Control Method	Sensorless Vector Control
Operating Temperature	-10°C to +50°C
Humidity	95% RH (non-condensing)
Protection Features	Over voltage, under voltage, over current, over temperature, short circuit, earth fault
Communication Options	Modbus RTU
Braking	Dynamic Braking Transistor standard
