INVT GD300L-004G-4 User Manual

Goodrive300-LIFT series inverter Commissioning guidelines
-87-
Function
code
Name
Recommended
value
Remarks
P02.00
Motor type
Determined motor
type
According to the parameter values on
the motor name plate
P02.01
Motor rated power
Parameter value on
the motor name
plate
P02.02
Motor rated
frequency
Parameter value on
the motor name
plate
P02.03
Motor rated rotation
speed
Parameter value on
the motor name
plate
P02.04
Motor rated voltage
Parameter value on
the motor name
plate
P02.05
Motor rated current
Parameter value on
the motor name
plate
P03 group
Vector control
Default value
Adjusted based on the running
conditions
P05.01
S1 function
selection
1
Upward running (FWD)
P05.02
S2 function
selection
2
Downward running (REV)
P05.03
S3 function
selection
19
Inverter enabling (ENA)
P05.04
S4 function
selection
8
Multi-step speed terminal 1 (MS1)
P05.05
S5 function
selection
9
Multi-step speed terminal 2 (MS2)
P05.06
S6 function
selection
10
Multi-step speed terminal 3 (MS3)
P05.07
S7 function
selection
17
Contactor feedback (TB)
P05.08
S8 function
selection
18
Brake feedback (FB)
P05.09
S9 function
selection
6
Fault reset (RET)
