Goodrive300-
LIFT
series in
verter
Installat
ion guide
-
17
-
4.2.5 Mul
tiple-inve
rter inst
allation
Parallel inst
a
llation
Warm air
Cool air
Figure 4-4 Par
allel inst
allation
Note
:
•
Before
installing
inverter
s
in
dif
ferent
sizes,
align
their
top
position
s
for
the
convenience
of
later
maintenan
ce.
•
The minimu
m spa
ce of B, D and
C is 100m
m.
20
22
