INVT GD300L-1R5G-S2 User Manual

Goodrive300-LIFT series inverter Commissioning guidelines
-93-
inverter stops, and outputs contactor releasing command and lift stop signal (Y1). By now, one
operation cycle ends.
7.5.5 Distance control
Function
code
Name
Recommended value
Remarks
P02.14
Pulley diameter
100–2000mm
500mm
P02.15
DEC ratio
0.50–50.00
1.00
P21.00
control
0x00–0x11
Ones place: Enable control over the distance
between high-speed running and creeping
0: Disabled; 1: Enabled
Tens place: Enable control over the distance
between creeping and stop
0: Disabled; 1: Enabled
0
P21.01
High-speed running
DEC distance
0.200-3.000m
1.800
P21.02
Medium- and
low-speed DEC
distance
0.100-3.000m
1.000
P21.03
DEC distance for
creeping to stop
0.010-1.000m
0.080
P21.04
UP DEC adjustment
distance
-0.300–0.300m
0.000
P21.05
Down DEC
adjustment distance
-0.300–0.300m
0.000
P21.06
High-speed step of
multi-step speed
running
0–7
3
P21.07
Medium- and
low-speed step of
multi-step speed
running
0–7
1
P21.08
Creeping step of
multi-step speed
running
0–7
0
