INVT GD300L-1R5G-S2 User Manual

Goodrive300-LIFT series inverter Function parameters
-74-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
Bit6: Enable CD signal correction
Bit7: Disable sin/cos segmented speed
detection
Bit8: Autotuning without detecting encoder faults
Bit9: Enable Z-pulse detection optimization
Bit10: Disable Z-pulse correction optimization
Bit12: Stop and clear the Z-pulse arrival signal
P20.08
Offline detection
enabling of Z
pulse
Z pulse offline fault is ENC1Z. Z pulse detection
can be enabled to avoid wrong stopping or
control loss which is caused by Z pulse loss
when spindle stopping or incremental encoder is
used in SM control.
0: Disable
1: Enable
0
○
P20.09
Initial angle of
Z-pulse
Relative angle of encoder Z pulse to motor
magnetic position.
Setting range: 0.00–359.99
0
○
P20.10
Pole initial angle
Relative angle of encoder position to motor
magnetic position.
Setting range: 0.00–359.99
0
○
P20.11
Reserved
Reserved
0
◎
P20.12
Speed
optimization
enabling
0: Disable
1: Enable
1
○
P20.13
CD signal gain
0.80–1.20
1.00
◎
P20.14
C signal bias
0–4095
2048
◎
P20.15
D signal bias
0–4095
2048
◎
P20.16
Reserved
0–65535
0
○
P20.17
Reserved
0–65535
0
○
P21 Group Distance control
P21.00
Enable distance
control
0x00–0x11
Ones place: Enable control over the distance
between high-speed running and creeping
0: Disabled; 1: Enabled
Tens place: Enable control over the distance
between creeping and stop
0: Disabled; 1: Enabled
0
◎
