Goodrive300-LIFT series inverter Commissioning guidelines
-84-
Function
code
Name
Recommended value
Remarks
P05.02
S2 function selection
2
Downward running (REV)
P05.03
S3 function selection
19
Inverter enabling (ENA)
P05.04
S4 function selection
8
Multi-step speed terminal 1
(MS1)
P05.05
S5 function selection
9
Multi-step speed terminal 2
(MS2)
P05.06
S6 function selection
10
Multi-step speed terminal 3
(MS3)
P05.07
S7 function selection
17
Contactor feedback (TB)
P05.08
S8 function selection
18
Brake feedback (FB)
P05.09
S9 function selection
6
Fault reset (RET)
P05.12
HDI terminal
3
Maintenance
P06.01
Y output
1
Running feedback output
P06.04
Relay 1 output
4
Fault output (EO)
P06.05
Relay 2 output
7
Brake control (FC)
P06.06
Relay 3 output
8
Contactor control (TC)
P08.04
Brake close delay
0.1s
P08.05
Brake release delay
0.10s
P08.06
Brake feedback
detection time
2.0
P08.08
Contactor feedback
detection time
2.0
P08.15
Inverter stop delay
0.10s
P09.00
Multi-step speed 0
0 (Zero speed)
Set based on user control
requirements. The speed of step
0 is set to 0 m/s.
P09.01
Multi-step speed 1
Re-leveling speed
P09.02
Multi-step speed 2
Creeping speed
P09.03
Multi-step speed 3
Emergency speed
P09.04
Multi-step speed 4
Reserved
P09.05
Multi-step speed 5
Normally low speed
P09.06
Multi-step speed 6
Normally high speed 1
P09.07
Multi-step speed 7
Normally high speed 2
P09.09
S-curve ACC start
segment duration
2.0s
Adjusted based on the onsite
commissioning
P09.10
S-curve ACC end
segment duration
2.0s
