Goodrive350 series high-performance multi-function inverter Chapter 6
-211-
Function
code
Name
Detailed parameter description
Default
value
Modi
fy
coefficient
P24.17
Pulse filer
processing
0x0000–0xffff
Bit0: Enable/disable encoder input filter
0: No filter
1: Filter
Bit1: Encoder signal filter mode (set Bit0 or Bit2 to 1)
0: Self-adaptive filter
1: Use P20.18 filter parameters
Bit2: Enable/disable encoder frequency-division
output filter
0: No filter
1: Filter
Bit3: Reserved
Bit4: Enable/disable pulse reference filter
0: No filter
1: Filter
Bit5: Pulse reference filter mode (valid when Bit4 is
set to 1)
0: Self-adaptive filter
1: Use P24.19 filter parameters
Bit6–15: Reserved
0x0011
○
P24.18
Encoder pulse
filter width
0–63
0 means 0.25us
39
○
P24.19
Pulse reference
filter width
0–63
0 means 0.25us
39
○
P24.20
Pulse number of
pulse reference
0–65535
1024
◎
P24.21
Enable angle
compensation of
synchronous
motor
0–1
0
○
P24.22
Switch-over
frequency
threshold of
speed
measurement
mode
0–630.00Hz
1.00Hz
○
P24.23–
P24.24
Reserved
variables
0–65535
0
○
