Goodrive350 series high-performance multi-function inverter Chapter 5
-78-
Functio
n code
Name
Detailed parameter description
Default
value
P08.02
Acceleration time 3
0.0–3600.0s
Depend
on model
P08.03
Declaration time 3
0.0–3600.0s
Depend
on model
P08.04
Acceleration time 4
0.0–3600.0s
Depend
on model
P08.05
Declaration time 4
0.0–3600.0s
Depend
on model
P08.19
Switching frequency of
acceleration/deceleration time
0.00–P00.03 (max. output frequency)
0.00Hz: No switch over
If the running frequency is larger than
P08.19, switch to acceleration
/deceleration time 2
0
P08.21
Reference frequency of
acceleration/deceleration time
0: Max. output frequency
1: Set frequency
2: 100Hz
Note: Valid for straight-line
acceleration/deceleration only
0
P08.28
Automatic fault reset times
0–10
0
P08.29
Automatic fault reset time
interval
0.1–3600.0s
1.0s
5.5.8 Frequency setup
GD350 series inverter supports multiple kinds of frequency reference modes, which can be
categorized into two types: main reference channel and auxiliary reference channel.
There are two main reference channels, namely frequency reference channel A and frequency
reference channel B. These two channels support simple arithmetical operation between each other,
and they can be switched dynamically by setting multi-function terminals.
There is one input mode for auxiliary reference channel, namely terminal UP/DOWN switch input. By
setting function codes, users can enable the corresponding reference mode and the impact made on
the inverter frequency reference by this reference mode .
The actual reference of inverter is comprised of the main reference channel and auxiliary reference
channel.
