INVT GD350-2R2G-4

Goodrive350 series high-performance multi-function inverter Chapter 5
-87-
Function
code
Name
Detailed parameter description
Default
value
10: Analog AI1 input value
11: Analog AI2input value
12: Analog AI3 input value
13: Input value of high-speed pulse
HDIA
14: Set value 1 of MODBUS
communication
15: Set value 2 of MODBUS
communication
16: Set value 1 of PROFIBUS\CANopen
communication
17: Set value 2 of PROFIBUS\CANopen
communication
18: Set value 1 of Ethernet
communication
19: Set value 2 of Ethernet
communication
20: Input value of high-speed pulse
HDIB
21: Reserved
22: Torque current (bipolar, 100%
corresponds to 10V)
23: Exciting current (100% corresponds
to 10V)
24: Set frequency (bipolar)
25: Ramps reference frequency
(bipolar)
26: Running speed (bipolar)
P06.17
Lower limit of AO1 output
-100.0%–P06.19
0.0%
P06.18
Corresponding AO1 output of
lower limit
0.00V–10.00V
0.00V
P06.19
Upper limit of AO1 output
P06.17–100.0%
100.0%
P06.20
Corresponding AO1 output of
upper limit
0.00V–10.00V
10.00V
P06.21
AO1 output filter time
0.000s–10.000s
0.000s
P06.22–
P06.26
Reserved variable
0–65535
0
P06.27
Lower limit of HDO output
-100.0%–P06.29
0.0%
