Goodrive350 series high-performance multi-function inverter Chapter 9
-258-
-100.0–+100.0% (unit: 0.1%)
-100.0–+100.0% (unit: 0.1%)
0.00–10.00V (unit: 0.01V)
0.00–10.00V (unit: 0.01V)
-10.00–10.00V (unit: 0.01V)
Read input of
high-speed pulse 1
0.00–50.00kHz (unit: 0.01Hz)
Read input of
high-speed pulse 2
Read current step of
multi-step speed
-300.0–+300.0% (unit: 0.1%)
The Read/Write (R/W) characteristics indicate whether a function can be read and written. For
example, "Communication-based control command" can be written, and therefore the command code
6H is used to control the inverter. The R characteristic indicates that a function can only be read, and
W indicates that a function can only be written.
Note: Some parameters in the preceding table are valid only after they are enabled. Take the running
and stop operations as examples, you need to set "Running command channel" (P00.01) to
"Communication", and set "Communication running command channel" (P00.02) to the Modbus
communication channel. For another example, when modifying "PID setting", you need to set "PID
reference source" (P09.00) to Modbus communication.
The following table describes the encoding rules of device codes (corresponding to the identification
code 2103H of the inverter).
