INVT Goodrive350 Series

Goodrive350 series high-performance multi-function inverter Appendix A
-270-
Field identifier
Field description
Naming example
05: Canopen communication card
06: DeviceNet communication card
07: BACnet communication card
08: EtherCat communication card
09: PROFINET communication card
10: 485 communication card
EC- IO 5 01 - 00
① ② ③ ④ ⑤
Field identifier
Field description
Naming example
①
Product category
EC: Extension card
②
Card category
IO: IO extension card
TX: Communication extension card
PG: PG card
PC: PLC programmable card
③
Technical version
Indicates the generation of a technical version by
using odd numbers, for example, 1, 3, and 5
indicate the 1
st
, 2
nd
, and 3
rd
generations of the
technical version.
④
Distinguishing code
01: Multiple-function I/O extension card (4 digital
inputs, 1 digital output, 1 analog input, 1 analog
output, and 2 relay outputs)
02: Digital I/O card
03: Analog I/O card
04: Reserved 1
05: Reserved 2
⑤
Special requirement
The following table describes extension cards that Goodrive350 series inverters support. The
extension cards are optional and need to be purchased separately
Name
Model
Specification
IO extension card
EC-IO501-00
• 4 digital inputs
• 1 digital output
• 1 analog input
• 1 analog output
• 2 relay outputs: 1 double-contact output, and 1
single-contact output
Programmable
EC-PC501-00
• Adopting the global mainstream development
