INVT Goodrive350 Series User Manual

Goodrive350 series high-performance multi-function inverter Appendix C
-309-
Table C.5 Flange installation dimensions of 660 V inverters (unit: mm)
Inverter
specification
W1
W2
W3
W4
H1
H2
H3
H4
D1
D2
Installation
hole
diameter
Fixing
screw
22kW–45kW
270
130
261
65.5
555
540
516
17
325
167
7
M6
55kW–132kW
325
200
317
58.5
680
661
626
23
363
182
9.5
M8
160kW–220kW
500
180
480
60
870
850
796
37
358
178.5
11
M10
C.5.3 Floor installation dimensions
W4
W2
W2
H1
H2
D1
W1
W3
D2
D2
3- ø13.0
6- ø12.0
Fig C.19 Floor installation diagram of inverters of 660 V, 250 to 350 kW
W1
W2
W2
H1
H2
3- ø22.0
D1
D2
D2
W3
6- ø12.0
Fig C.20 Floor installation diagram of inverters of 660 V, 400 to 630 kW
