Goodrive350 series high-performance multi-function inverter Chapter 5
-54-
Detailed parameter description
only P12.06, P12.07 and P12.08 will be
autotuned.
0: Asynchronous motor
1: Synchronous motor
Speed loop proportional
gain 1
Speed loop integral time 1
Switching low point
frequency
Speed loop proportional
gain 2
Speed loop integral time 2
Switching high point
frequency
P03.02–P00.03 (max. output frequency)
0–8 (corresponds to 0–2
8
/10ms)
Electromotion slip
compensation coefficient of
vector control
Brake slip compensation
coefficient of vector control
Current loop proportional
coefficient P
Current loop integral
coefficient I
Torque setup mode
selection
1: Set via keypad (P03.12)
2: Set via AI1 (100% corresponds to three
times of rated motor current)
3: Set via AI2 (the same as above)
4: Set via AI3 (the same as above)
5: Set via pulse frequency HDIA (the same
as above)
6: Set via multi-step torque (the same as
above)
7: Set via MODBUS communication (the
same as above)
8: Set via PROFIBUS/CANopen/DeviceNet
communication (the same as above)
