INVT SPC Series User Manual

SPC Series Solar Pump Inverter Function parameter list
-29-
Function
code
Name
Description
Default
Modify
37: Switch the running command channel
to terminal
38: Switch the running command channel
to communication
39: Pre-exciting command
40–42: Reserved
43: Full-waterl signal
44: Empty-water signal
45–63: Reserved
P05.10
Input terminal
polarity
The function code is used to set the
polarity of input terminals.
When a bit is 0, the input terminal is
positive;
When a bit is 1, the input terminal is
negative.
BIT0
S1
Setting range: 0x0–0xF
0x0
◎
P06 group Output terminals
Function
code
Name
Description
Default
Modify
P06.03
RO output
0: Disable
1: Running
2: Running forward
3: Running reversely
4: Jogging
5: Inverter in fault
8: Frequency reached
9: Running in zero speed
10: Upper limit frequency reached
11: Lower limit frequency reached
12: Ready for running
13: Pre-exciting
14: Overload pre-alarm
15: Underload pre-alarm
1
○
