INVT SPC Series User Manual

SPC Series Solar Pump Inverter Function parameter list
-48-
Function
code
Name
Description
Default
Modify
P17.05
Motor rotation
speed
0–65535RPM
0 RPM
●
P17.11
DC bus voltage
0.0–2000.0V
0V
●
P17.12
Digital input
terminal status
0x0–0xF
Bit 0 corresponds to S1. Bit 1
corresponds to S2.
0x0
●
P17.13
Digital output
terminal status
0x0–0xF
Bit 0 corresponds to RO1.
0x0
●
P18 group Status viewing functions special for solar inverter
Function
code
Name
Description
Default
Modify
P18.00
PV reference
voltage
MPPT is performed at the inverter side.
The value is given by the inverter side.
0.0V
●
P18.01
Actual PV
voltage
DC input voltage (V)
0.0V
●
P18.03
Actual PV
current
DC input current (A)
0.00A
●
P18.07
PV input power
Reserved. Unit: kW
0.00kW
●
P18.11
Actual pump
flow
*/Q Q f f
NN

Unit: m
3
/h
0.0m
3
/h
●
P18.12
Actual pump lift
2
0.9 * ( / )H H f f
NN

Unit: m
0.0m
●
P18.13
High-order bits
in total pump
flow
Used to display the 16 high-order bits of
the total pump flow. Unit: m
3
0
●
P18.14
Low-order bits
in total pump
flow
Used to display the 16 low-order bits of
the total pump flow. Unit: m
3
Total pump flow = P18.13*65535 +
P18.14
0.0
●
P18.15
Reset total
pump flow
When it is set to 1, the total pump flow
can be reset. P18.13 and P18.14 are
cleared and then accumulated again.
After the resetting succeeds, P18.15 is
automatically changed to 0.
0
◎
