INVT SPC Series User Manual

SPC Series Solar Pump Inverter Options
-58-
Output reactor model selection
Inverter model
Output reactor
SPC2K2TR20
OCL2-004-4
SPC2K2TR26-S
OCL2-004-4
SPC2K2TR26-H
OCL2-004-4
SPC004TR40
OCL2-004-4
SPC004TR46-S
OCL2-004-4
SPC004TR46-H
OCL2-004-4
SPC7K5TR40
OCL2-7R5-4
SPC7K5TR46-S
OCL2-7R5-4
SPC7K5TR46-H
OCL2-7R5-4
Note:
 The rated output voltage drop of output reactors is 1%±15%.
 All the options in the preceding table are externally configured. You need to specify
whether the options are externally configured in your purchase order.
