ION FALCO - Technical Specification

FALCO Instrument User Manual V1.2R
Unrivalled Gas Detection. Page 12 of 46 ionscience.com
The main display uses organic light emitting diode (OLED) technology and the status bar uses light emitting
diodes (LED). It also has a galvanically separated 4-20 mA current loop, Modbus (serial communication
protocol) and two configurable switched contacts.
For protection in explosive areas the FALCO’s Main Unit electronics are fitted in an ExD enclosure and the PID
Sensor Head utilises intrinsically safe electronics.
The FALCO has two modules:
• The Main Unit (flameproof enclosure)
• The PID Sensor Head (intrinsically safe)
The externally located intrinsically safe PID Sensor Head allows servicing and calibration in a hazardous
environment without having to isolate the power supply.
Technical Specification
Name
VOC Analyser Falco 1.2
Dimensions
h 291 mm, w 180 mm, d 125 mm
Weight
3.3 kg
Nominal Voltage
12V to 40Vdc (Powered from Safety Extra-Low (SELV))
Maximum Current
0.56 A at 12 V / 6.6 W
0.28 A at 24 V / 6.7 W
0.2 A at 40 V / 8 W
Maximum Power
8W
Typical Power
2W (depending on the LED intensity)
Supply Cables
0.5 to 2.5mm
2
Maximum Contact Load
60Vdc / 2A
50Vac / 2A
Internal Voltage 4-20mA
19V ± 1V
Fuse
Fuse T 1A (blow value 35A)
Operating Temperature:
-20°C to + 50°C
Operating Humidity:
0 – 100 RH% (condensing)
Storage Temperature
-20°C to +60 °C
Ingress Protection
Main Unit: IP65
Sensor Head: IP65
PID Sensor
MiniPID
II 1G Ex ia IIC
Baseefa 07ATEX0060U
Measuring Range
0 to 10ppm, 0 to 50ppm, 0 to 1,000ppm, 0 to 3,000ppm. Falco
TAC.
0 to
50ppm
T
90
< 10 seconds
Accuracy
+/- 5% +/- 1 digit
