IPCAM User Manual
9 / 67
2.2.2 Interface
Figure 1.2
LAN : RJ-45/10-100 Base T
DC5V : 5V/2A Power supply
I/O PINS: 1)Output(GND) 2)Output (+5V) 3)Alarm input 4)Input (GND) (you can see 3.5.6
For more information)
Figure 1.3
RESET BUTTON: Press and hold down the RESET BUTTON for 5 seconds.Release the
power button
and IP camera will be reset back to the factory default parameter
2.3 PC System Requirements
System configuration requirements: ( Example for view four IP Camera )
CPU: 2.06GHZ or above Memory: 256M or above
Network Card: 10M or above Display Card: 64M or above memory
Recommendable Operating System: Windows2000 ，Windows XP，VISTA,WIN7
Support web browser: IE. FireFox. Google etc .
WIFI antenna
RJ-45 Ethernet
