iPECS LIK50 - Hardware Components

- LIK50 Description & Installation
Issue 1.2.1
5
1.2 HARDWARE COMPONENTS
Table 1.2-1 provides a description of the hardware components that make-up iPECS-LIK50 . All of
these Modules and terminals are connected over a 10/100 Base-T Ethernet LAN.
Table 1.2-1 Modules and Terminals of iPECS-LIK50
ITEM DESCRIPTION
1
LIK-MFIM50A
Multi-Function Interface gateway Module, 50 ports w/Analog trunk
LIK-MFIM50B
Multi-Function Interface gateway Module, 50 ports w/ISDN-BRI
2
AC/DC Adapter
AC/DC Adapter MFIM50A/B module (12VDC, 1.5A)
3
AC/DC Adapter –K-
AC/DC Adapter for LIP Phones and DSS Console (48VDC, 0.3A)
4
DHLD
Desk mount Holder for module
5
DHE
Desk mount Holder Extender, one (1) required for each Module
6
WHLD
Wall mount Holder for module
7
1U-RMB
1U Rack mount Bracket
8
LIP-7004N
LIP Phone, Basic 4 button no display
9
LIP-7008D
LIP Phone, 8 button and basic 2-line display
10
LIP-7016D
LIP Phone, 16 button, 3-line display w/Menu, Soft & Nav. buttons
11
LIP-7024D
LIP Phone, 24 button, 3-line display w/Menu, Soft & Nav. buttons
12
LIP-7024LD
LIP Phone, 24 button, Large display w/Menu, Soft & Nav. buttons
13
LIP-7048DSS
LIP DSS Console with 48 buttons
14
LIP-8002
LIP Phone, 4 button and 1-line display, LAN 1 port
15
LIP-8004D
LIP Phone, 4 button and 1-line display, LAN 1 port
16
LIP-8012D
LIP Phone, 12 button, 3-line display w/Menu, Soft & Nav. buttons
17
LIP-8024D
LIP Phone, 24 button, 4-line display w/Menu, Soft & Nav. buttons
18
LIP-8040L
LIP Phone, 10 button, 9-line display w/Menu, Soft & Nav. buttons
19
LIP-8048DSS
LIP DSS Console with 48 buttons
20
LIP-8012DSS
LIP DSS Console with 12 buttons
21
LIP-8012LSS
LIP DSS Console with 12 buttons, w/12-line LCD button label
22
LIP-7004WMK
Wall Mount Kit for LIP-7004N
23
LIP-7008WMK
Wall Mount Kit for 7008D
24
LIP-7024WMK
Wall Mount Kit for LIP-7016D, 7024D & 7024LD
25
WIT-300HE/400H
iPECS WLAN Phone
25
WIT-400H
iPECS WLAN Phone
26
GDC-400B
DECT Base Station
27
GDC-600B
DECT Base Station
28
GDC-400H
DECT Handset
29
GDC-450H
DECT Handset
* Note: All iPECS-LIK modules can be connected to iPECS-LIK50 over a 10/100 Base-T Ethernet. Refer to
the iPECS-100/300/600/1200 Description and Installation manual.
