iPECS LIK50 - Interface Specifications; Maximum Station Distance from Gateway Module

- LIK50 Description & Installation
Issue 1.2.1
25
3.4.2 Interface Specifications
Table 3.4.2-1 Interfaces
Interfaces
Specifications
Ethernet
Connector
Ethernet
Maximum Wiring Distance
RJ-45 unshielded
10/100 BASE-T
100m / 0.328Kft
USB
Connector
Mode
USB Female Plug type A
Host V 1.1
RS-232
Connector
DB-9, 3 -wire
FXS Connector
Loop Distance
Ring Capacity
Ring Frequency
RJ-45
3 Km, AWG #24 (0.5mm)
3 US REN (US 7K model)
25Hz
FXO
Connector
REN (Ringer Equivalent Number)
RJ-45
0.7B
ISDN-BRI
Connector
Network Type
RJ-45
T interface
3.4.3 Maximum Station Distance from Gateway Module
Table 3.4.3-1 Maximum Station Wiring Distance
ITEM
AWG 22 (m/Kft)
AWG 24 (m/Kft)
LIP Phone
100/0.328
100/0.328
SIP or H.323 VoIP phone
100/0.328
100/0.328
Single Line Telephone (FXS)
6,000/20
4,000/13
Note 1 All the LIP Phones are compliant to IEEE 802.3af POE standards. In addition, according to the standards, LIP Phones all
operate over distances of up to 100 meters from the switch.
