2.1.2 AD/DC adapter for LIK-MFIM50 Modules
LIK-MFIM50A/B, Figure 2.1.3-1, are packaged with an AC/DC adapter. The adapter is supplied
with a two (2) meter (six (6) foot) AC cord terminated with the nationally relevant AC blade
type. The adapter supports AC input power systems with rated voltage range of
100-240 VAC @ 50/60 Hz. The adapter provides 12 VDC, 1.5A amps. The DC output connector is
cabled to the adapter with a two (2) meter (six (6) foot) cable.
LIK-MFIM50A/B use a 12Vdc/1.5A AC/DC adapter. Before connecting the AC/DC
adapter to an LIK-MFIM50A/B , please check the rated output voltage of the Adapter.
Figure 2.1.3-1 AC/DC adapter MFIM50A/B
