- LIK50 Description & Installation
Issue 1.2.1
24
3.2 DIMENSION AND WEIGHT
Table 3.2-1 Dimensions and Weight
ITEM
HEIGHT
(mm/in)
WIDTH
(mm/in)
DEPTH
(mm/in)
WEIGHT
(kg/lbs)
LIK-MFIM50A/B
230/9.1
38.8/1.5
194.5/7.7
0.7/1.54
1U RMB
38.3/1.5
482.6/19
183.27.2
2/4.4
DHLD *
1
146/5.7
111.5/4.4*
1
128/5
0.4/0.9
WHLD
280/11.0
60/2.4
188.3/7.4
0.2/0.4
Note 1 The width of the Desk mount does not include approximately 40mm/3.2 inches for each installed module.
3.3 ENVIRONMENT SPECIFICATION
Table 3.3-1 Environmental Specifications
DEGREES (
0
C)
DEGREES (
0
F)
Operation Temperature
Optimum Operation Temperature
Storage Temperature
Relative Humidity
0~40
32~104
20~26
68~78
-20~60
-4~140
0~80% non-condensing
3.4 ELECTRICAL SPECIFICATIONS
3.4.1 System Electrical Specification
Table 3.4.1-1 System Electrical Specifications
SPECIFICATIONS
AC/DC Adapter for MFIM50A/
- AC Voltage Input
- AC Power
- DC Output Power
100-240 VAC, +/-10% @ 50/60 Hz
0.5 A
12 VDC, 1.5 A max
AC/DC Adapter for LIP Phones
- AC Voltage Input
- AC Power
- DC Output Power
100-240 VAC, +/-10% @ 50/60 Hz
0.5 A
48 VDC, 0.3 A
External Relay Contact
2 A @ 30 VDC
Music Source Input
0 dBm @ 600 ohm
External Paging Port
0 dBm @ 600 ohm
