2.2.2 LIP-7000 series Phones
The LIP-7000 series IP phones are available in five (5) models as well as a matching DSS/BLF
Console. Models available include:
LIP-7004N, 4-button non-display
LIP-7008D, 8-button 2-line display
LIP-7016D, 16-button 3-line display
LIP-7024D, 24-button 3-line display
LIP-7024LD, 24-button large display
LIP-7048DSS, 48-button DSS/BLF Console.
Each of the above models and Wall Mount kits are shown Figure 2.2.2-1 in to Figure 2.2.2-6. The
LIP-7004N and 7008D have a single LAN port for connection to the external 10/100 Base-T LAN.
The LIP-7016D, 7024D and 7024LD models have two (2) LAN ports and thus two (2) RJ-45
connectors. One port is for connection to the LAN, the other can be connected to the desktop data
device (PC) or other LAN interface terminal. The ports are connected to an intelligent 10/100 Base-
T switch, which gives LAN access to the data device while giving priority to voice packets.
The LIP-7048DSS Console, which is used to expand the number of Flexible buttons available to a
user by 48 buttons, has two (2) LAN ports. When the console is locally powered with the AC/DC
Adapter, the LIP-7048DSS Console can be connected to the PC LAN port of the LIP-7016D,
7024D or 7024LD.
Each LIP-7000 series phone has a standard 12-button dial-pad, color coordinated handset, an
array of 4 (four) to twenty-four (24) “Flexible buttons”, and fixed feature access buttons. All of the
Flexible and most Fixed buttons, incorporate a long-life, super-bright LED to indicate the circuit or
feature status.
The fixed feature buttons for each model include the following:
LIP-7004N
OHD (Off-Hook Dial)
Hold/Save
Volume Control
Speed (preprogrammed Flex button)
Trans/gm (preprogrammed Flex button)
LIP-7008D
Speaker (Speakerphone)
Hold/Save
Volume Control
Speed
Trans/Pgm
Dnd (preprogrammed Flex button)
Call Back (preprogrammed Flex button)
To Next Page
