2.2 LIP PHONES & TERMINALS
iPECS-LIK50 works with a number of telephone types including standard SLTs, VoIP phones (SIP
or H.323 v3) and the LIP Phones. The LIP Phones are available in several models as shown in
Table 2.2-1.
Table 2.2-1 LIP Phones
MODEL
DESCRIPTION
LIP-7004N
Basic LIP Phone, 4 Flex buttons, no display
LIP-7008D
LIP Phone w/8 Flex buttons and 2 line display
LIP-7016D
LIP Phone w/16 Flex buttons, 3-line display, Navigation and soft-keys
LIP-7024D
LIP Phone w/24 Flex buttons, 3-line display, Navigation and soft-keys
LIP-7024LD
LIP Phone w/24 Flex buttons, Multi-line large display, Navigation and soft-keys
LIP-7048DSS
LIP DSS Console with 48 Flex buttons,
LIP-7004WMK
Wall Mount Kit for LIP-7004N
LIP-7008WMK
Wall Mount Kit for 7008D
LIP-7024WMK
Wall Mount Kit for LIP-7016D, 7024D & 7024LD
WIT300HE/400H
iPECS WLAN Wireless Phone
LIP-8002
LIP Phone, 4 button and 1-line display, LAN 1 port
LIP-8004D
LIP Phone, 4 button and 1-line display, LAN 1 port
LIP-8012D
LIP Phone, 12 button, 3-line display w/Menu, Soft & Nav. buttons
LIP-8024D
LIP Phone, 24 button, 4-line display w/Menu, Soft & Nav. buttons
LIP-8040L
LIP Phone, 10 button, 9-line display w/Menu, Soft & Nav. buttons
LIP-8048DSS
LIP DSS Console with 48 buttons
LIP-8012DSS
LIP DSS Console with 12 buttons
LIP-8012LSS
LIP DSS Console with 12 buttons, 12-line display
Note: All LIP Phones are compliant to IEEE 802.3af standards.
2.2.1 LIP-8000 series Phones
The LIP-8000 series phones are available in four models as well as three models of matching
DSS/BLF Consoles. The models include:
LIP-8002, 4-button 1 line display
LIP-8004D, 4-button 1 line display
LIP-8012D, 12-button 3 line display
LIP-8024D, 24-button 4 line display
LIP-8040L, 10-button large display
LIP-8048DSS, 48-button DSS/BLF Console
LIP-8012DSS, 12-button DSS/BLF Console
LIP-8012LSS, 12-button 12 line LCD DSS/BLF Console
Each of the above models is shown in Figure 2.2.1- to Figure 2.2.1-7. The LIP-8004D has a single
LAN port for connection to the external 10/100 Base-T LAN. The other phones in the LIP-8000
series have two (2) LAN ports and thus two (2) RJ-45 connectors. One port is for connection to
the LAN, the other can be connected to the desktop data device (PC) or other LAN interface
