iPECS LIK50 - WHLD (Wall Mount Holder); 1 URMB (1 U Rack Mount Bracket)

- LIK50 Description & Installation
Issue 1.2.1
21
2.3.2 WHLD (Wall mount HoLDer)
LIK-MFIM50A/B can be individually wall mounted in the WHLD (module Wall
Mount Holder), shown in Figure 2.3.2-1. The WHLD provides wall mounting for a single module.
Figure 2.3.2-1 Module Wall Mount Holder
2.3.3 1URMB (1U Rack Mount Bracket)
LIK-MFIM50A/B can be individually wall mounted in the 1U RMB (1U Rack Mount
Module), shown in Figure 2.3.2-1. The 1URMB provides wall mounting for a single module.
Figure 2.3.3-1 1URMB (1U Rack Mount Module)
