Keep in mind the following conditions when installing LIP-8000 DSS consoles.
1) The AC/DC adapter must be used for LIP-8048DSS.
2) Up to two (2) LIP-8012LSS and/or LIP-8012DSS can be installed with LIP-8000 Phone.
3) The LIP-8048DSS must be separately powered.
Figure 4.5-2 LIP-8000 DSS
Installation
Figure 4.5-3 LIP-8000 DSS Installation (12DSS +
48DSS)
