| LaserNet software
78
YLS-K
Item Designation Description
1 Menu bar Via the menu bar, you have access to the menus,
submenus and options of the software. Various
settings can be configured in LaserNet using the
5 main menus.
2 Laser selection You can manage multiple lasers via the LaserNet
software. All lasers that have been connected to
the software are shown in this field. If the net-
work connection to a laser is deactivated, this is
indicated by an X over the laser icon. If a net-
work connection to a laser is active, the red X
over the corresponding laser icon disappears.
3 Power and tem-
perature display
displays the current output power and mean
temperature of the selected laser.
4 Tab Status messages, warnings and alarms as well as
operating parameters are displayed in the tabs.
In addition, you can configure settings relating
to laser operation in some tabs (e.g., Control).
The number and type of the tabs varies depend-
ing on the configuration of the laser.
5 Connection status Displays the status of the network connection to
the selected laser.
6 Status indicator Laser ON – Laser power supply is ON / OFF
Laser ready – Laser is ready / not ready to en-
able the laser radiation.
Chiller ready – Chiller is ready / not ready.
Chiller ready is a prerequisite for Laser ready.
Guide laser – If no chiller is configured, the sta-
tus of the guide laser is displayed instead of
Chiller ready.
Laser error – Laser has/does not have a fault.
7 Operating display Depending on the tab, the status messages,
warnings and alarms as well as the display
fields for performance data or temperature val-
ues are located in this field.
Table8: Description of the LaserNet user interface
8.6 LaserNet menu description
The table below provides an overview of the LaserNet menu structure.
A detailed description of the individual menus can be found in the fol-
lowing sections of this operating manual.
