IRIS 700 Series User Manual

IRIS MODEL 700/800 APPLICATION MANUAL
PAGE 14
FIGURE 2 - MODEL 700AC SIGNAL PROCESSOR WIRING
AC IN
GROUND
TO VIEWING
HEAD
24 V BACKUP BATTERY
(OPTIONAL)
0-20 OR 4-20 MA
FOR INDICATOR OR
INSTRUMENTATION
360 OHMS MAX
+
-
+
-
+
+26VDC
GND
.125 A
LIM
.4A
2
A
CHASSIS,
EARTH, OR
SYSTEM GND
AC POWER
SUPPLY
APPROVED
-t°
