IRIS MODEL 700/800 APPLICATION MANUAL
PAGE 34
SPECIFICATIONS FOR SERIES 700 AND 800 VIEWING HEADS
MODELS S702, S702-PF, S702-HF, S702-HF-PF, S706, S706-PF,
AND MODELS S802, S802-HF, AND S806
ELECTRICAL
Input Power - 22VDC to 26VDC, 150 mA MAX from Model 700AC,
Model 700DC or Model 800 Signal Processor
ENVIRONMENTAL
Viewing Head Sealing - NEMA TYPE 4/4X rated when the molded connector
ring is tightened with pliers and a UV protection is
provided for the cable.
Ambient Temperature - -40°C to 85°C (-40°F to 185°F)
IR DETECTOR SPEC
(S702, S702-PF, S702-HF,
S702-HF-PF, S802, S802-PF) - InGaAs (Indium Gallium Arsenide) photodiode with
spectral response 950nm to 1710nm
(1/2 intensity points)
High Pass Filter Pickup - 33 Hz standard, 155 Hz High Freq. option (-HF)
IR OPTICAL
Angle of View - 1 degree (1.45” dia. at 6 ft.)
UV DETECTOR SPEC
(S706 & S706-PF, S806) - UVtron with spectral response 185nm to 260nm
UV OPTICAL
Angle of View - 5 degrees (1 inch per foot)
CABLE & CONNECTOR
(Signal Proc. to V.H.) - (Standard) IRIS SYSTEMS C-330, 4 Conductor, 18
ga., shielded, 90C, Sunlight Resistant, 15 ft. long,
with ITC rating for US and CIC rating for Canada.
(This rating permits use in hazardous locations
without a conduit.)
- With PF option 4 conductor, 22 ga. or larger with
overall braided shield, 95% coverage, or with
shield over the signal line. Tie shield to ground at
viewhead end and signal processor end of cable.
(Cable must be protected by a conduit in
hazardous locations.)
