IRIS MODEL 700/800 APPLICATION MANUAL
PAGE 19
FIGURE 8 - MODEL S802 AND S806 VIEWING HEADS
HEX 1.50" ACROSS FLATS
1/4" - 18 NPT FOR PURGE AIR
1/2" - 14 NPT FOR SIGHTING PIPE
7.72"
6.01"
1.13"
0.40"
1.50"
1.76" DIA MOUNTING BLOCK
DIA
