IRIS MODEL 700/800 APPLICATION MANUAL
PAGE 35
SPECIFICATIONS FOR MODEL 700AC & MODEL 700DC SIGNAL PROCESSORS
ELECTRICAL – MODEL 700AC
Primary Input Power - 85-265VAC, 50-60 HZ, 0.07A MAX. fused (with
either V.H. connected)
Battery Backup Voltage - 22VDC to 26VDC, 0.2A DC MAX. fused (with either
V.H. connected)
ELECTRICAL – MODEL 700DC
Primary Input Power - 22VDC to 26VDC, 250 mA MAX, fused (with either
V.H. connected)
Battery Backup Voltage - 22VDC to Input Voltage -.5VDC, fused (with either
V.H. connected)
OUTPUTS
Flame Relay - 2 form C contacts
Self-Checking Relay - 1 form C contact
Relay Contact Ratings - 5A at 125 VAC, 277 VAC, & 30 VDC; 1/8 HP 125 &
250 VAC
Analog Flame Signal - isolated 0 to 20 mA or 4 to 20 mA output for remote
meters or DCS, 360 ohms maximum resistance
ENVIRONMENTAL
Ambient Temperature - 0°C to 50°C (32°F to 122°F)
MODEL 800 SIGNAL PROCESSOR SPECIFICATIONS
ELECTRICAL
Primary Input Power - 85-265VAC, 50-60 HZ, 0.10A MAX. fused (with
either V.H. connected)
OUTPUTS
Flame Relay - 2 form A contacts
Flame Relay Contact Ratings - 5A at 125 VAC, 250 VAC, and 30 VDC
Self-Checking Relay - 1 form A contact
Self-Check Relay
Contact Ratings - 0.4A: 110 VDC, 125 VAC; 2A: 30VDC
Analog Flame Signal - 0 to 20 mA or 4 to 20 mA output for remote meters
or DCS, non-isolated, 100 ohms maximum
resistance
ENVIRONMENTAL
Ambient Temperature - 0°C to 60°C (32°F to 140°F)
Rev 01/05
