IRIS 700 Series User Manual

IRIS MODEL 700/800 APPLICATION MANUAL
PAGE 21
FIGURE 11 - MODEL 700 VIEWING HEAD CABLE WITH 1/2” NPT FITTING
FIGURE 12 - MODEL 700/800 VIEWING HEAD CABLE CONNECTIONS
RED
BLACK
WHITE
GREEN
TERMINAL
VH SIG
VH SC
VH +V
VH GND
CONDUIT
ENCLOSURE
S702-PF, S702-HF-PF or S706-P
F
SHIELD
GRAY CABLE
WITH OVERALL SHIELD
STANDARD "PIGTAIL" LENTH = 20 INCHES
TERMINAL
VH SIG
VH SC
VH +V
VH GND
RED
BLACK
WHITE
GREEN
SHIELD
VIEWING HEAD
CONNECTOR
LOOKING AT PINS
VH SC
VH GND/SHIELD
VH +V
VH SIG
RED
BLACK
WHITE
GREEN
TERMINAL
VH SIG
VH SC
VH +V
VH GND
SHIELD
C-330 LIGHT BLUE CABLE
WITH SHIELDED WHITE CONDUCTOR
(RATED ITC BY UL & CIC BY CSA)
GRAY CABLE
WITH OVERALL SHIELD
GREEN
LED
ORANGE
LED
VIEWING HEAD
CONNECTOR
LOOKING AT BACK
700 LTA
Con74
Cdt02
.307"
MAX
.250"
MAX
METAL
CONNECTOR RING
