IRIS 700 Series User Manual

IRIS MODEL 700/800 APPLICATION MANUAL
PAGE 27
BNR-OFF
SEQ
START/END
Press BNR-OFF SEQ again to end taking
burner off data or wait until the count reaches zero
(15 seconds minimum recommended)
A
S
-
P
2
UTO ETUP AGE
BNR-OFF
SEQ
START/END
Press BNR-OFF SEQ to
begin taking burner off data
Display begins counting
down from 59 seconds
Press reset at any time during this
procedure to cancel auto setup
RESET
rE
NOTE:
Press BNR-ON SEQ again to end taking
burner on data or wait until the count reaches zero
(30 seconds minimum recommended)
BNR-ON
SEQ
START/END
Display returns to current flame signal
and AUTO SETUP OFF SEQ light flashes
Turn burner off
Display begins counting
down from 29 seconds
Is the auto setup
ratio acceptable?
RATIO < 72%
Ratio is acceptable
Display
‘- -’ for one second
and new values are saved
shows new ratio
setting for one second,
then
CONTINUED NEXT PAGE
NORMAL OPERATION
Y
N
FLOW CHART 3 - AUTO SETUP PAGE 2
