IRIS MODEL 700/800 APPLICATION MANUAL
PAGE 22
SIDE VIEW
BOTTOM VIEW
TD (A)
TD (B)
RD (A)
RD (B)
+12VDC
SG. GND
12456
RS-422
RS-232
RS-232/RS-422
CONVERTER
MODEL 422IRIS
3
RS-232/RS-422 CONVERTER
TD (A)
TD (B)
RD (A)
RD (B)
+12VDC
SG. GND
12456
3
+12 VDC POWER SUPPLY
NC
MODULAR CONNECTOR
WIRING
CAUTION: The order of the colors in the cable can be TYPE A or TYPE B. Check colors at
the connector.
FIGURE 13 - WIRING OF RS-422 TO RS-232 CONVERTER TO MODEL 700 SIGNAL
PROCESSOR
MODULAR
CONN.
SCHEM
LABEL
COLOR
TYPE A
COLOR
TYPE B
INTERFACE
LABEL
DESCRIPTION
POWER
SUPPLY
1NCWHIBLUNC NC -
2 TX- BLK YEL RD (A)
FROM
M700
-
3 TX+ RED GRN RD (B)
FROM
M700
-
4 RX- GRN RED TD (A)
TO
M700
-
5 RX+ YEL BLK TD (B)
TO
M700
-
6 GND BLU WHI GND GROUND GND
+12VDC POWER +12VDC
