IRIS 700 Series - Page 24

IRIS MODEL 700/800 APPLICATION MANUAL
PAGE 24
FIGURE 15 - PROGRAMMER AND CABLE
BOTTOM VIEW
1
24563
124563
OF MODULAR CONNECTOR
(TO PINS ON MODULAR CONNECTOR)
PLUG INTO
EITHER JACK
TO PIN 2
TO PIN 4
TO PIN 6
2.98"
5.52"
6 FT.
